CMYK offset sublimation ink for fabric printing-passed SGS,D

CMYK offset sublimation ink for fabric printing-passed SGS,D

For our sublimation offset ink ,first print image on sublimation paper, second put the paper on fabric, and then press the paper with transfer machine. Under the temperature about ...


Get Quote        Get More Help

CMYK offset sublimation ink for fabric printing-passed SGS,DGM


Advantages of
offset sublimation
 ink
1. High transfer rate.
2. Excellent color reproduction, gorgeous color, not color cast.
3.No crust in 28-30 days (open the cover),save 20% compared with other ink when printing on machine
4. Applicable to synthetic fabrics such as polyester fabric, smooth feel comfortable, no hard feeling.
5.Transferred pattern scratch-resistant, washable, non-cracking, no peeling, no fading, and good weather resistance.


1. Use Principle of
offset sublimation ink
It is used on all kinds of offset machine. With the ink,first print image on paper with the offset press, then transfer the image onto various materials by heat transfer press, especially for polyester fabric. Under high temperature, the ink will become gas and go into fabric.

2. Use Scope of
offset sublimation ink
It can be used on all kinds of offset machine. (single-color, two-color and multicolor offset printing machine which supply single paper once)

3. Transfer Paper

Coated paper, offset paper, chrome paper and cardboard paper.

4. Suitable Fabrics
Polyester fabric, Triacetate fabric, Nylon fabric, Acrylic fabric, Polypropylene nitrile. (All kinds of synthetic fabrics)

5. Colors
Magenta, Yellow, Cyan, Black (or other colors according to customer’s requirements).

6. Use Method
(1)Be able to adapt to the demand for middle-speed or high-speed printing.
(2)During the normal condition, use the ink on the machine directly.

7. The printing process just needs 3 steps

(1)Print the image on paper, and normal paper is ok.
(2)Put the printed paper on substrate, such as polyester and nylon fabric.
(3)Put the paper and fabric on the heat-transfer machine. When the temperature reaches 180-220°C, the image will be transfer printed from paper onto the substrate.

8.  Product Characteristics Product characteristics
* No Crust
a.Granula size is less than 5 micron.
b.No crust in 28-30 days. (open the cover)

* Safety
Passed SGS,DGM,MSDS,totally environment-friendly!

* Advantages
Good stability on the machine,clear dot reproduction,excellent ink-water balance.
Be able to adapt to the demand for middle-speed or high-speed printing.
During the normal condition, use the ink on the machine directly.

*P.S. please make samples before the final printing to confirm the exactly image.

9. Transfer temparature
About 185~220°C

10. Transfer time
About 20~40 seconds

11. Application examples
a.To get 50%C on fabric,the color on paper should be 30%C
b.To make red PS-plate,the ratio is 100%M and 35%-40%Y
c.To make blue PS-plate,the ratio is 100%C and 20%M
d.To make green PS-plate,the ratio is 80%C and 90%Y
e.To get yellow like Asian skin,the ratio is 10%~11%M and a little cyan.Cyan can be adjusted according to your requirment

12. For alumina plate,stainless steel plate,copper plate and porcelain with coating,the transfer temperature can refer to the above table.

The following is the transfer printing parameters for your reference



Name of fabric Transfer temperature pressure Time
Polyester fabric 205°C~220°C 0.5kg/cm2 10~30 seconds
Polyester deformation fabric low elastic 195°C~205°C 0.5kg/cm2 30 seconds
Triacetate fabrics 190°C~200°C 0.5kg/cm2 30~40 seconds
Nylon fabric 195°C~205°C 0.5kg/cm2 30~40 seconds
Acrylic fabric 200°C~210°C 0.5kg/cm2 30 seconds
Two acetate fiber fabric 185°C 0.5kg/cm2 15~20 seconds
Polypropylene nitrile 190°C~220°C 0.5kg/cm2 10~15 seconds


Dye degree:(European Standard)



Color fastness
Color Magenta Yellow Blue Black
Rank 5-6 6 5 6



Please be noted
The control of the colors is always carried out after the transfer of the final supports.
The relationship between the temperature and the time of contact is important in order to have the optimal color resistance and ink penetration (the longer the time of transfer, the better the ink penetration of the fabric).
